WorkCentre 3210/3220 Multifunction Printer Service Manual 1-5
General Information
Rear View
1. Telephone Line Connector 6. DIMM Cover
2. Extension Connector 7. Handle
3. Power Switch 8. 15-pin Optional Tray Connection
4. Power Receptacle 9. Ethernet Port
5. Rear Cover 10. USB Port
