Xerox WORKCENTRE 3210

8-58 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Covers
Front Cover
PL2.0.1
1. Remove tray 1.
2. Open the Front Cover.
3. Carefully press the left or right latch toward the center to release the Front
Cover from the notch.
4. Slide the Front Cover out at angle and remove the Front Cover.
s3210mfp-234
