8-4 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Notations in the Disassembly Text
■ The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
■ The notation “PLX.X.X” indicates that this component is listed in the Parts
List.
■ Bold arrows in an illustration show direction of movement when removing
or replacing a component.
■ The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Provides information specific to the replacement of parts or
assemblies.
