8-64 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Connect the fan wiring harness to the Main Controller Board. Place
the front side of the Right Cover at an angle to secure the latch of the
Right Cover to the notch on the printer frame while sliding the Right
Cover toward the printer.
To Next Page
