WorkCentre 3210/3220 Multifunction Printer Service Manual 8-89
Service Parts Disassembly
6. Remove the Duplex Actuator (page 8-84).
7. Disconnect the Paper Empty Sensor wiring harness connector.
8. Remove the Paper Empty Sensor.
s3210mfp-051
Latch
