WorkCentre 3210/3220 Multifunction Printer Service Manual 9-5
Parts List
Parts List 1.0 Main
ID No. Name/Description Part Number
0. 24 PPM, Mono Laser MFP (3210)
28 PPM, Mono Laser MFP (3220)
1. ELA HOU-Frame_220V
ELA HOU-Frame_110V
2. Main Controller PBA (3210)
Main Controller PBA (3220)
140N63400
140N63399
3. HVPS 105N02147
4. SMPS 110V (Power Supply)
SMPS 220V (Power Supply)
105N02162
105N02163
5. CBF Harness-Fuser AC
6. Harness-SMPS
7. CBF Harness-HVPS
8. Drive Unit Assembly 007N01601
9. CBF Harness-Motor & Solenoid
10. CBF Harness-AC-Inlet
11. Transfer Roller 022N02354
12. LSU Unit (Laser Unit) 122N00279
13. Duplex Unit 022N02410
14. Rear Cover Assembly 002N02734
15. Right Cover Assembly 101N01442
16. Left Cover Assembly 101N01443
17. Cassette Assembly (Tray) 050N00542
18. Front Cover Assembly 101N01440
19. Middle Cover Assembly 101N01444
20. ELA HOU-Scan_High
ELA HOU-Scan_Low
21. Print Cartridge - 2K
Print Cartridge - 4K
Print Cartridge - 4K (DMO - only)
106R01485
106R01486
106R01487
22. FAX_Board Cover
23. Screw-Taptite
24. FAX Board 140N63240
25. Power Cord 110V
Power Cord 220V
105N02072
117N01769
30 Terminator (220 V Only) 114N00078
