WorkCentre 3210/3220 Multifunction Printer Service Manual 9-13
Parts List
28. Shaft-Feed
29. Gear-Feed DR 16
30. Ground-Guide TR
31. Spring-TS
32. Cam-M-Pick Up
33. Ring-CS;ID3,OD3,T0.25,BLACK,SU
34. Exit Idle Gear 007N01630
35. Feed Gear 007N01631
36. Bracket-Feed
37. Pick Up Solenoid 121N01168
38. Screw-Taptite
39. Laser Unit Fan 127N07572
40. Holder Power
41. Shield-Power_SWITCH
42. Plate-Power CAP
43. Ground-SCF
44. PBA LED-Panel
45. Frame-LSU-Holder-R
46. Frame-LSU-Holder_L
47. Upper Exit Frame 001N00515
48. Gear-M-Fuser Idle 1
49. Ring-CS
50. CBF Harness-LSU SW&Fan
52. Terminal-CRUM
53. SUB Terminal PBA 140N63398
54-1.
54-2.
54-3.
54-4.
Holder-Exit Roller
Roller-Exit Main
Roller-Exit FR
Spring CS
55. Gear-M-Exit
56. PMO-Bearing Shaft
57. Support-Roller
59. Exit Roller 022N02409
63. Shield-CONT Roller
64. Shield-SMPS
65. Insulation-SMPS
Parts List 4.0 Frame (continued)
ID No. Name/Description Part Number

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
