WorkCentre 3210/3220 Multifunction Printer Service Manual 9-15
Parts List
102. Spring ETC-Guide DEVE
103. PMO-Plate Guide DEVE_R
104. Spring TR
105. Bush-TR_L
106. Terminal Spring TR
107. PMO-Bushing_TR(L)
108. Guide-Holder_TR
109. Spring ETC-ES (Guide holder TR)
110. Holder-Transfer
111. Link Cover_Rear
112. Spring-CS
114. Rear Guide Unit 032N00491
115. Bush-4
116. Harness-CCD Home
117. Harness-Fuser SMPS
Parts List 4.0 Frame (continued)
ID No. Name/Description Part Number
To Next Page
