WorkCentre 3210/3220 Multifunction Printer Service Manual 9-17
Parts List
Parts List 5.0 Drive Unit Assembly
ID No. Name/Description Part Number
0. Drive Unit Assembly 007N01601
1. Bracket Gear
2. Gear Exit RDCN 61/28
3. Gear RDCN 83/40
4. Gear Fuser DR IN 61
5. Gear RDCN 89/55
6. Gear OPC DR IN 89
7. Gear Feed RDCN 56/25
8. Gear Pick Up Idle 31
9. Gear RDCN 52/18
10. Gear OPC Clutch 29
11. Gear Fuser DR OUT 37
12. Washer Plain
13. Bracket Motor
14. Motor BLDC
15. Screw Taptite
16. -----
17. -----
18. Ring C
19. Hub Clutch
20. Spring Clutch

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
