WorkCentre 3210/3220 Multifunction Printer Service Manual 9-31
Parts List
Parts List 8.0 Fuser
ID No. Name/Description Part Number
0. Fuser (110V)
Fuser (220V)
126N00330
126N00331
1. Cover Fuser
2. PMO Roller Upper DP
3. Roller Idle
4. IEX Shaft Idle, F/Up
5. Thermistor 130N01489
6. Screw Taptite
7. Thermostat 130N01490
8. Screw Taptite
9. Ground Fuser
10. Heat Roller 022N02356
11. Gear Fuser
12. Bush HR-L
13. Bush HR-R
14. PEX Roller F/Up (2)
15. Spring ETC
16. Guide Claw
17. Spring ETC Claw
18. Spring TS
19. Exit Actuator 120N00524
20. Frame Fuser
21. Large Pressure Roller 022N02357
22. Bush PR-1st
23. Small Pressure Roller 022N02358
24. Bush PR-2nd
25. Lever Link Jam-R
26. Lever Link Jam-L
27. Spring CS
28. Ring-C
29. Spring ES
30. Halogen Lamp, 110V
Halogen Lamp, 220V
122N00269
122N00270
31. CAP Lamp-L 122N00286
32. CAP Lamp-R 122N00287
33. Gear Fuser RDCN 28-20
34. Gear MPF 5
35. Washer Plain
36. Ring CS
37. Exit Sensor 130N01274
38. Exit Actuator Cover
39. Junction Block

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
