Xerox WORKCENTRE 3210

WorkCentre 3210/3220 Multifunction Printer Service Manual 9-33
Parts List
Parts List 9.0 Duplex Unit
ID No. Name/Description Part Number
0. Duplex Unit 022N02410
1. Frame Duplex Base
2. Terminal GND-DUP L
3. Terminal GND-DUP S
4. Bush M Feed, DUP
5. Roller Feed-DUP2
6. Ring-C
7. Pulley M-18 Dummy-DUP
8. Pulley 18-DUP
9. Gear Exit F/Down
10. Belt Timing Gear
11. Belt Timing Gear
12.
12-1.
12-2.
ELA Unit Roller-DUP
Roller Feed-DUP
Ring-C
13. Bracket Duplex-Align
14. Screw Tapping
15. Guide Duplex-Upper
16. Roller M-Idle-DUP
17. PCT-SILP Washer
18. Shaft Idle Roll, DUP
19. Spring-TS
20. Screw Taptite
