WorkCentre 3210/3220 Multifunction Printer Service Manual 9-35
Parts List
Parts List 10.0 Optional Tray Assembly
ID No. Name/Description Part Number
0. Optional Tray Assembly 098N02204
1. Cassette Assembly (Tray) 050N00542
2. Cover Front-SCF
3. Cover Right-SCF
4. Cover Left-SCF
5. Cover Rear-SCF
6. Duplex Cover 002N02736
7. Cover Rear Duplex
8. Screw Taptite
9.
9-1.
9-2.
9-3.
9-4.
9-5.
9-6.
9-7.
9-8.
9-9.
9-10.
9-11.
9-12.
ELA HOU Motor-SCF
Bracket Motor-SCF
Support Feed-SCF
Gear Idle 59
Gear 61/47 Idle
Gear Idle 23
Gear-35 Idle
Gear RDCN 57/18
Bracket Gear-SCF
Motor Step
PMO Impeller-DRV
Screw Taptite
Washer Plain
10.
10-1.
10-2.
10-3.
Pick Up Roll
Housing-M Pick Up R2
Rubber Pick Up
Housing-M Pick Up UP2-R2
130N01540
