WorkCentre 3210/3220 Multifunction Printer Service Manual 2-11
Theory of Operation
Document Feeder Functions
ADF Components
Components Description
Input Tray The input tray feeds documents into the ADF for simplex
(single-sided) scanning. Tray capacity is 50 sheets of paper
(20 lb. bond).
Output Tray Documents fed through the ADF exit to the output tray.
ADF Feeder
Assembly, ADF
Rubber Feed Pad
The ADF Feeder is designed to work with the ADF Rubber Feed
Pad to ensure that only one sheet of paper is fed at a time.
ADF Motor The ADF motor drives the pick and feed roller.
ADF Connector An electrical connector on the rear of the ADF connects to a
receptacle on the rear of the flatbed portion of the IIT. The ADF
connector communicates with the scanner board and that
communication is passed to the IOT.
ADF Hinges Mechanical connection between the ADF and the scanner
portion of the IIT consists of a set of hinges. These hinges
allow for the ADF to lift from the document glass to facilitate
book copying.

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
