WorkCentre 3210/3220 Multifunction Printer Service Manual 2-15
Theory of Operation
Halogen Lamp
■ Voltage
■ 120V: 115 V ± 5%
■ 220V: 230 V ± 5%
■ Capacity: 750 Watt ± 25 W
■ Temperature Distribution: 120%
Thermistor
The Thermistor detects the temperature of the heating unit and feeds the data
into the main processor.
Thermostat
When the Heat Lamp becomes too hot, the Thermostat cuts off power to the
lamp to prevent from overheating.
Heat Roller
The Heat Roller transfers heat from the lamp to the paper. As the paper
passes between the Heat Roller and Pressure Rollers, toner is melted and
permanently fixed to the paper. The surface of the Heat Roller is coated with
Teflon, so that toner does not stick to the surface.
Pressure Rollers
The Large and Small Pressure Rollers are made of a silicon resin and the
surface is coated with Teflon. When media passes between the Heat Roller
and the pressure rollers, toner is melted and permanently fixed to the surface
of the paper.
Safety Features
Several protection devices are used to prevent Fuser overheating:
■ Hardware cuts off Fuser power when overheating is detected.
■ Software cuts off Fuser power when overheating is detected.
■ Thermostat cuts off main power to the lamp.
Interlocks disable the Fuser, motors and Laser Unit.
■ Fuser power is cut off when the front cover is opened.
■ Fuser cover temperature is maintained at less than 80°F.

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
