WorkCentre 3210/3220 Multifunction Printer Service Manual 2-35
Theory of Operation
Laser Unit
The Laser Unit (LSU) receives image data from the PVC or HPVC and make
latent image on the OPC surface. The LSU uses dual beam system, LD1 and
LD2. The control method of the two beams are the same. In comparison with
a single beam system, dual beam contains half of the LSU’s frequency.
The LSU consists of laser diode (LD) and the polygon motor control. When
the printing signal occurs, the laser diode is turned On and the polygon motor
is enabled. When the light sensor detects the beam, H-SYNC occurs. When
the polygon motor speed becomes steady, Ready mode occurs. If these two
conditions are satisfied, the Laser Unit is ready. If the two conditions are not
satisfied, one of the two errors are reported as shown in the table below:
Error Description
Polygon Motor Error When the polygon motor speed is not steady.
H-SYNC Error The Polygon Motor speed is steady, but the H-SYNC is
not generated.

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
