OPERATING THE TRANSCEIVER

USING A CROSSPATCH

ENVOY™ TRANSCEIVER REFERENCE MANUAL 83

Related links:

Selecting a peripheral device on page 195

Selecting information to be shown in a status area on page 28

Changing the operating mode of the crosspatch

To change the operating mode of the crosspatch:

1 If you are using a 2220 Handset or 2230 Desk Console, press 5.

1 If you are using a 2221 Handset:

• From the main menu, select (Functions).

• Press or to scroll to the Next Crosspatch State function.

•Press (OK).

The crosspatch toggles between the following states:

•Off

•Active

• Standby

NOTE: If the status shows Disconnected, the crosspatch may not be

connected.
