SCAN TABLES
OVERVIEW OF SCAN TABLES
ENVOY™ TRANSCEIVER REFERENCE MANUAL 129
Figure 41: Information for a scan table
Related links:
Overview of channels on page 118
Channel dwell time on page 130
Overview of HF networks on page 140
Adding a scan table on page 133
Scan Mute on page 229
Global on page 144
Scan Tables
Table 1
HF Networks*:
Scan:
Voice Detect:
Channel Dwell Time:
Selcall, CALM
Not selected
Selected
Auto
Table 2
Scan Channels: Ch 01/USB
Ch 03/USB
Data: Selected
HF Networks*:
Scan:
Voice Detect:
Channel Dwell Time:
Selcall, CALM
Selected
Selected
Auto
Scan Channels: Ch 02/USB
Ch 04/USB
Data: Not selected
All
HF Networks*:
Scan:
Voice Detect:
Channel Dwell Time:
ALE
Not selected
Not selected
Auto
Scan Channels:
Ch 02/USB
Ch 04/USB
Data: Not selected
Ch 01/USB
Ch 03/USB
* read-only entry
