MODES
OVERVIEW OF MODES
282 ENVOY™ TRANSCEIVER REFERENCE MANUAL
Overview of modes
Information about the modes available in the transceiver is stored in User Data >
Modes. A mode specifies a combination of a sideband (for example, USB or LSB)
and IF filter values (that is, bandwidth and centre frequency).
Each channel must have at least one mode. You may want to select several modes for
each channel depending on the modes available to you.
Related links:
Overview of channels on page 118
Available modes
The transceiver comes with a set of standard modes, and other modes may be added
with software options. Table 11 lists the modes that may be available within your
transceiver. The modes that appear for selection with a channel are the allowed modes.
Table 11: Modes
Name of
mode
Sideband Rx/Tx IF centre
(Hz)
IF width
(Hz)
Standard/Option
USB USB Rx/Tx 1500 2400 Standard
LSB LSB Rx/Tx 1500 2400 Standard
AM AM Rx 0 6000 Standard
AM AM Tx 1500 2400 AM filter option
USBW USB Rx/Tx 1675 2750 2750 Hz filter option
LSBW LSB Rx/Tx 1675 2750 2750 Hz filter option
USBXW USB Rx/Tx 1800 3000 3000 Hz filter option
LSBXW LSB Rx/Tx 1800 3000 3000 Hz filter option
UMCW USB Rx/Tx 900 500 500 Hz filter option
LMCW LSB Rx/Tx 900 500 500 Hz filter option
CW USB Rx/Tx 900 500 500 Hz filter option
