PERIPHERALS
SELECTING A PERIPHERAL DEVICE
ENVOY™ TRANSCEIVER REFERENCE MANUAL 195
Selecting a peripheral device
When you connect a peripheral device to the 15-way or 6-way connector, you can set
up how the port operates automatically by selecting the peripheral device from the list
of supported devices for the connector.
NOTE: Codan peripheral devices are listed by their type number, for example,
3031 Crosspatch. The type number for a Codan device is located on the
front or serial number escutcheon.
To select a peripheral device:
1 From the main menu, select (User Data), then (Peripherals).
1 Press or to select the icon corresponding to the connector to which the
peripheral device is attached.
1 Press or to scroll to the type of peripheral device that is attached to the
connector, then press OK.
If there are settings that you can change to optimise this peripheral for your
requirements, is shown to the right of the peripheral name when it is selected.
1 If you want to change settings for the peripheral, press to see the list of entries
that you may change.
If the value of an entry for a peripheral device has been changed from the default
value, is shown next to the title of the entry.
1 Press (Save) to automatically update settings for correct operation of the
connected peripheral device.
1 If you added a peripheral device, restart your transceiver to activate the new
settings.
Related links:
Overview of peripherals on page 192
