CHANNELS
ENTRIES FOR A CHANNEL
120 ENVOY™ TRANSCEIVER REFERENCE MANUAL
Modes
Modes are available in the transceiver when a particular filter is enabled. When the
standard IF filter is enabled, the available modes are USB and LSB. If a different filter
is enabled, other modes are available. For example, if you have a wide IF filter
enabled, USBW and LSBW are available. If you have a narrow Morse filter enabled,
UMCW and LMCW are available.
You can select any or all of the available modes as the allowed modes for a particular
channel. You select the preferred mode from the allowed modes for a particular
channel.
Related links:
Modes on page 281
Preferred mode
The optional preferred mode is the mode that the transceiver uses by default when this
channel is selected. The preferred mode is selected from the list of allowed modes for
the channel.
Power
The Power entry sets the power level for transmission when this channel is selected.
The actual value that may be selected for each range is set up in the Low Power,
Medium Power and High Power entries in Settings > Configuration.
If you want the transceiver to transmit signals on this channel at:
• the power level set in the Tx Power entry, select Leave as is
• the value set for the low power range, select Low
• the value set for the medium power range, select Medium
• the value set for the high power range, select High
Related links:
Low Power on page 221
Medium Power on page 221
High Power on page 222
