CONNECTORS

CONNECTORS ON THE DESK CONSOLE

ENVOY™ TRANSCEIVER REFERENCE MANUAL 375

USB connector

The USB connector is on the back panel of the desk console. It is a standard

micro-USB connector.

Foot-switched PTT connector

The Foot-switched PTT jack is on the back panel of the desk console. It is a 3.5 mm

(1/8 in) jack.

Table 25: Pinouts of the Foot-switched PTT connector

Connection Function Input/output Signal level

Sleeve N/C

Tip PTT (+) Input Active low, pull-up to 3.3 V

Ring Return (–) Ground
