NAVIGATING THE MENU STRUCTURE

OVERVIEW OF BASIC AND ADVANCED VIEWS

ENVOY™ TRANSCEIVER REFERENCE MANUAL 95

Switching between basic and advanced views

The user can switch between basic and advanced views to either:

• simplify the user interface of the control point (basic view), or

• access advanced settings that they are permitted to change (advanced view)

To switch between views:

1 Press until the main menu screen is shown.

1 From the main menu, select (Advanced View).

1 Press OK to toggle advanced view on or off as required.

1 Press (Save).

NOTE: You can also use the + 2 hot-key sequence to toggle the user

interface between basic and advanced views.
