OPERATING THE TRANSCEIVER

SETTING THE DISPLAY TIMEOUT

42 ENVOY™ TRANSCEIVER REFERENCE MANUAL

Setting the display timeout

You can set the length of time that the display and keypad backlight remains on after

the last activity on the control point. After this time, the backlight value drops to Low.

When a key is pressed, the backlighting returns to the value set in the Brightness

entry.

To set the display timeout:

1 From the main menu, select (General), then (Brightness).

1 Press to move to the Set Auto Dim Time tab.

1 Press or to scroll to the value that you want to set, then press OK.

1 Press (Save) to save the information.

Related links:

Setting the brightness of the display on page 41
