OPERATING THE TRANSCEIVER

PERFORMING A SELF-TEST

86 ENVOY™ TRANSCEIVER REFERENCE MANUAL

Performing a self-test

The Envoy™ Transceiver has a series of built-in tests that may be completed to assess

a particular aspect of functionality.

To perform a self-test:

1 From the main menu, select (General), then (Self Tests).

By default, all self-tests are selected.

1 If there is a test that you do not want to perform, press or to scroll to the

test, then press OK.

1 Press (Start).

1 Follow any on-screen prompts.

At the end of the test a summary of outcomes is provided.

1 Press (Close).

Related links:

Selecting/deselecting a check box on page 108
