SETTINGS

SETTINGS > GPS

252 E

NVOY™ TRANSCEIVER REFERENCE MANUAL

My Position

The My Position entry enables you to enter static GPS information for a fixed

station, which typically does not have a GPS receiver attached. The transceiver uses

this reference information to perform automatic distance and bearing calculations to a

waypoint.

NOTE: Automatic distance and bearing calculations only occur when the GPS

Call option is installed.

NOTE: The space between the latitude/longitude number and the direction

indicator is optional.

Default value: no selection

Table 8: Format of My Position information

Latitude Longitude Altitude, UTC, and type of reading

DDMM.SSS N/S

0 < D < 90

0 < M < 60

0 < S < 60

DDDMM.SSS E/W

0 < D < 180

0 < M < 60

0 < S < 60

3452.810 S 13841.280 E +12.5M 041725 (M)

3452.810S 13841.280E
