FREE TUNE

OVERVIEW OF FREE TUNE

284 ENVOY™ TRANSCEIVER REFERENCE MANUAL

Overview of free tune

The transceiver can be used as a free-tune receiver. This enables you to tune to any

frequency within the transceiver’s operating range of 250 kHz to 30 MHz.

In some circumstances, the options installed in your transceiver may enable you to

transmit while free tuning, for example, the Amateur Mode option enables you to

transmit during free tune when tuned to a frequency in the amateur band.

Table 12: Amateur Band frequencies

Frequency

(MHz)

1.8 to 2.0

3.5 to 4.0

5.06 to 5.45

7.0 to 7.3

10.1 to 10.15

14.0 to 14.35

18.0 to 18.2

21.0 to 21.45

24.8 to 25.0

28.0 to 29.7
