Settings > Connectors > RFU 15way
The connector settings for the transceive
r are set automatically according to the
requirements of the peri
pheral device connected.
Related links:
Peripherals
on page 191
RFU Secure Audio
The
RFU Secure Audio
entry sets whether or not secure audio is present on the
15-way port.
Default value:
Disabled
247
249
