USING THE WIZARD

12 ENVOY™ TRANSCEIVER REFERENCE MANUAL

Using the wizard

The wizard should start automatically when a new transceiver is powered up for the

first time.

Figure 7: Wizard Startup screen

NOTE: If the wizard screen doesn’t launch automatically, follow the

instructions below. If your transceiver has been profiled using TPS, the

wizard may not be available.

To use the wizard:

1 Press PTT, then press (Menu) to return to the top level of the menu

structure.

1 Check that the icon for the wizard is highlighted ( ), then press (OK).

1 Press (Yes) to confirm that you want to start the wizard.

If you want to bypass the wizard, press (No).
