OPERATING THE TRANSCEIVER

SELECTING A LANGUAGE

ENVOY™ TRANSCEIVER REFERENCE MANUAL 39

Selecting a language

The default language for the control point is English, however, you may have other

language options available for the control point.

Figure 12: Select Language screen

To select a language:

1 From the main menu, select (Select Language).

1 Press or to scroll to the language that you want to use on the control point,

then press OK.

1 Press (Save) to save the information.

1 Press (Yes) to confirm that you want to change the language.
