Selecting an antenna

NOTE: If a Dual Antenna Adaptor is used with a 9103 and tuned whip on one

of the antenna ports, you must select 9103.

To select an antenna:

1 From the main menu, select (User Data), (Peripherals), then

(Antenna Type).

1 Press or to scroll to the antenna type that you want to use, then press OK.

1 Press (Save) to save the information.

1 Restart the transceiver to activate the new settings, if requested.
