DATA OPTIONS
MIL/STANAG 2G DATA
ENVOY™ TRANSCEIVER REFERENCE MANUAL 311
Selecting MIL/STANAG 2G Data as a peripheral device
MIL/STANAG 2G Data is connected to a computer via the 6 or 15-way connector on
the RFU using cable 08-07318-00x or 08-06952-00x respectively. You must select the
MIL/STANAG 2G Data Interface as a peripheral device for the connector.
To select the peripheral device:
1 From the main menu, select (User Data), then (Peripherals).
1 Press or to select (RFU 6way) or (RFU 15way).
1 Press or to scroll to the MIL/STANAG Data Interface option, then
press OK.
1 Press (Save) to save the information.
1 Restart the transceiver to activate the new settings, if requested.
Sending email via RC50-C
An email message is sent via your email client to the RC50-C HF Email software,
which passes it to the MIL/STANAG 2G Data processor. The processor passes the
message to the transceiver, which transmits it over the air.
To send an email message:
1 Launch the RC50-C HF Email software, then click Go Online to activate the
MIL/STANAG 2G Data processor.
The transceiver responds with a beep.
1 Compose your email message in your email client software, for example
Microsoft® Outlook®, then send it to the recipient.
When a signal is transferred between the data modems across the link
established by the transceivers, the current transmit or receive data rate is
indicated on the right-hand side of the Clear Data indicator.
While the message is being sent between the transceivers, activity is reported on
the screen of the control point.
