OPERATING THE TRANSCEIVER
UPGRADING THE TRANSCEIVER VIA A USB STICK
84 ENVOY™ TRANSCEIVER REFERENCE MANUAL
Upgrading the transceiver via a USB stick
Firmware packages and profiles from TPS, and secure keys from KMS may be loaded
onto a USB stick, providing a portable method of upgrading transceivers in the field.
You can also read a profile from a transceiver in the field. When the USB stick is
connected to the control point, a selection menu is shown for various activities
depending on the values set in Settings > General > USB User Access.
To manage profiles, firmware, and secure keys:
1 Connect your USB stick to the control point using a standard USB A (female)
to micro USB cable (Codan part number 67-90406).
The USB stick is detected automatically. A Select Task icon ( ) is now
available in the main menu screen.
1 Enter the correct admin PIN, if requested.
1 Press or to scroll to the activity that you want to perform from the
following:
• If you want to program a profile from the USB stick to the transceiver,
select Program Profile.
• If you want to read the profile from the transceiver to the USB stick, select
Read Profile.
• If you want to upgrade the transceiver with a firmware package from the
USB stick, select Upgrade Firmware.
• If you want to program secure keys to a transceiver that has an encryptor
module enabled, select Program Secure Keys.
1 Do one of the following:
• Press or to scroll to the profile, firmware package, or key set file,
press (Options), scroll to Open, then press (Select).
• Press or to scroll to the folder in which you want to save the profile
from the transceiver, then press (Save).
1 Press (Yes) to confirm that you want to complete the selected action.
1 Perform more tasks with the USB stick as required.
1 Press (Eject) when you have finished working with the USB stick.
1 Remove the USB stick from the control point.
Related links:
USB User Access on page 206
