CIVS voice scrambler

NOTE: The CIVS option may be installed with CES and AES encryptors.

CIVS provides cost-effective, software-enabled voice scrambling. It is simple to use,

and provides a basic level of voice security. You can select from one of 32 fixed codes

that offer different levels of security. Lower CIVS code levels are more secure than

higher CIVS code levels.

Figure 62: Channel screen showing secure/clear status for CIVS voice

scrambler

Figure 63: Channel screen showing transmit/receive status for CIVS voice

scrambler

Related links:

Switching the secure feature on or off on page 77

Secure Clear

privacy code

Transmit Receive
