OPERATING THE TRANSCEIVER
FINDING AN RFU
E
NVOY™ TRANSCEIVER REFERENCE MANUAL 87
Finding an RFU
If your organisation has several RFUs and control points connected to a LAN via an
Ethernet switch, you have to allocate a different IP address to each unit in Settings >
Connectivity. When you enter the Find RFU screen, the transceiver searches for IP
addresses on the LAN and provides a list from which you can select.
To find and connect to an RFU:
1 From the main menu, select (General), then (Find RFU).
1 Press or to scroll to the RFU to which you want to connect, then press
(Connect).
1 If the RFU to which you want to connect is on a different subnet, do the
following:
• Press or to select the IP tab.
• Press to move to the Enter RFU Address entry.
• Enter the segments of the IP address.
You may need to press to move to the next segment.
•Press (Connect).
Related links:
Settings > Connectivity on page 258
