P
ERIPHE
RALS
E
NTRIES
FOR
A
PERIPHERAL
202
E
NVOY
™ T
RANSCEIVER
R
EFERENCE
M
ANUAL
RFU 6way MIL/STANAG 2G Data Interface
The
RFU 6way MIL/ST
ANAG 2G Data Interface
entry sets whether or not this
internal serial data interface
is connected to the 6-way
port. If you are connecting to a
computer with RC50-C via serial
cable 08-07318-00x, you must set this to
Enabled
.
Default value:
Disabled
223
225
