COMPLIANCE

EMC AND SAFETY NOTICES

474 ENVOY™ TRANSCEIVER REFERENCE MANUAL

WARNING: A protective earth connection must be included in the mains wiring to

the 3020 Transceiver Supply.

WARNING: The protective cover must always be fitted when the 3020 Transceiver

Supply is connected to the AC mains.

Earth symbols

Chassis earth connection points are provided on the Envoy™ Transceiver and

3020 Transceiver Supply. A protective earth is provided in the AC mains wiring of

the 3020 Transceiver Supply. This protective earth must be connected at the AC

mains supply outlet. The symbols shown below are used to identify the earths on the

equipment.

Table 46: Earth symbols

Symbol Meaning

Chassis earth

Protective earth
