OPERATING THE TRANSCEIVER

VIEWING INFORMATION ABOUT YOUR TRANSCEIVER

ENVOY™ TRANSCEIVER REFERENCE MANUAL 69

Viewing information about your transceiver

Overview of information in the transceiver

The transceiver contains information on:

• hardware options that have been fitted

• sales options that have been enabled

• the electronic serial number of the RFU

• the version status of the current firmware

•IP information

• licence information

Viewing device information

To view information in the transceiver:

1 From the main menu, select (Information), then (Device

Information).

The transceiver type, profile name, and fitted hardware options with respective

firmware version are listed.

1 If you want to view the sales options that are enabled in the transceiver, press .

1 Press (Close).
