CONNECTORS

CONNECTORS ON THE RFU

366 E

NVOY™ TRANSCEIVER REFERENCE MANUAL

6-way serial data connector

The 6-way connector is on a flying lead from the back of the 10-way connector.

The serial data (RS232) connector can be used for connecting peripheral devices to

the transceiver. By default, it is set up for a GPS receiver.

Figure 77: Front view of the 6-way connector

Related links:

Overview of peripherals on page 192

Table 20: Pinouts of the 6-way connector

Pin no. Function Input/output Signal level

1 A rail protected (2 A) Output +13.6 V nominal

2 Ground 0 V

3 RS232 Tx data A Output RS232

4 RS232 Rx data A Input RS232

5Spare

6 RS232 Rx data B Input RS232
