CHANNELS
WORKING WITH CHANNELS
124 ENVOY™ TRANSCEIVER REFERENCE MANUAL
1 Do one of the following:
• If there are no channels programmed in the transceiver, press (Add).
• If there are some existing channels programmed in the transceiver, scroll
to the channel after which you want to add the new channel, press
(Options), scroll to Add, then press (Select) to add a channel.
NOTE: The transceiver automatically generates a sequential
channel name based on the selected channel. If no channel
is selected, the transceiver uses the next available CH xx.
All information, except frequencies, is copied to the new
channel.
1 Enter the name that you want to use for the channel.
1 Press to move to the Tx entry.
1 Enter the transmit frequency that you want to use for this channel (in kHz, with
up to three decimal points or 1 Hz resolution).
1 Press to move to the Rx entry.
The Rx entry is automatically filled with the transmit frequency.
1 Enter the receive frequency (in kHz, with up to three decimal points or 1 Hz
resolution), if required to be different from the Tx frequency.
1 Press to move to the Mode entry.
1 To select a mode:
• Press to view the list of available modes.
• Press or to scroll to the mode that you want to use, then press OK.
When the check box is selected, the item is enabled. When the check box
is clear, the item is disabled.
• Select other modes, as required.
NOTE: The modes that you select become the allowed modes for
this channel. In a scan table, you can duplicate a channel
and select another of the allowed modes.
•Press (Save).
1 Press to move to the Preferred Mode entry.
1 Press or to select the mode that you want to use.
1 Press to move to the Power entry.
