E
NVOY
™ T
RANSCEIVER
R
EFERENCE
M
ANUAL
297
20
Data options
This section contains the following topics:
•
Overview of data options
on page 298
•
2.4
kbit/s Data Modem
on page 299
•
MIL/STANAG 2G Data
on page 308
•
RM50e HF Data Modem
on page 313
