DATA OPTIONS

2.4 KBIT/S DATA MODEM

ENVOY™ TRANSCEIVER REFERENCE MANUAL 307

Related links:

Selecting information to be shown in a status area on page 28

Red Variable length Red bar is indicative of the data throughput rate for the link.

Grey Solid The modem is enabled, but a computer is not communicating with it,

or the serial–USB cable is not connected correctly.

Check that VCOM is running as a background task. The USB–USB

connection with VCOM is recommended for base stations only.

Table 13: Status of the 2.4 kbit/s Data Modem (cont.)

Colour of

LED

State Description
