ENCRYPTION

CES-128 VOICE ENCRYPTION

ENVOY™ TRANSCEIVER REFERENCE MANUAL 351

1 Press .

1 Enter up to 16 digits for the base key.

1 Press (Save) to save the information.

1 Press (Close).
