INSTALLATION
FIXED STATIONS
ENVOY™ TRANSCEIVER REFERENCE MANUAL 419
Related links:
Earthing the antenna on page 416
Earthing the tuner on page 417
Earthing the transceiver in a fixed station on page 413
SWR is bad The SWR measurement
may have been performed
at the RFU rather than at
the antenna
Ensure the SWR meter is connected to the coaxial
line at the base of the antenna to achieve an
accurate reading.
The antenna may not be
positioned correctly
Check that the position of the antenna corresponds
to the desired direction of communication. The
antenna must also be positioned away from trees,
buildings etc, which provide a shielding effect and
diminish the efficiency of the antenna.
With an SWR meter in place, alter the position of
the antenna to achieve best forward-radiated
power.
Faulty coaxial cable or
control cable
Replace faulty cables.
The antenna and/or tuner
may not be earthed
correctly
Improve the earth connection.
Antenna detunes Inadequate support of the
antenna
Ensure the antenna has adequate support so that it
does not sway or sag. If required, use antenna
supports such as guyed masts.
Control point
disconnects from
RFU
Inadequate earthing of the
antenna
Improve the earth connection.
