COMMUNICATIONS
PRODUCT REFERENCE GUIDE
193
Distance to Trigger Line State
Select Upstream or Downstream. This parameter specifies if the distance from the physical
Trigger Line is required Upstream or Downstream (i.e. Trigger Source) to the expected receiving
point of the Protocol Index, measured in mm or inches. It is used together with the Minimum
Distance Between Two Consecutive Objects (below) parameter to assign the Protocol Index
information to the correct package. This option allows the camera to recognize a protocol
index message even if it occurs upstream such as a message from a scale.
Min Distance Between Two Consecutive Objects
Enter the smallest possible distance between system packages in the field provided. This
specifies the minimum distance (in mm or inches) between two consecutive packages. It is
used to compensate for imprecision in the Distance from Protocol Index to Trigger Line
parameter by virtually lengthening the package. This parameter implies that if two consecutive
packs are placed on the conveyor at a distance less than the minimum, Protocol Index
assignment error will occur and the camera will not assign the message to either package.
Log Type
Select Disable, Standard, or Advanced from the drop-down list. Advanced Logging is used
during calibration or troubleshooting to confirm that the protocol index message is solidly
found on the correct box.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values.
