•Protocol Index: Indicates the programmed protocol index string data
•
Parcel Length: Indicates the approximate length of the package
•
Parcel Width: Indicates the approximate width of the package
•
Parcel Height: Indicates the approximate height of the package
•
Parcel Volume: Indicates the approximate volume of the package
•
Parcel Orientation Angle: Indicates the angle of the package
•
Parcel Isolated: indicates it is not a side-by-side condition as detected by the
Dimensioning system.
•
Image Filename: Includes the filename of the image
Code Definition Number
Click the drop-down to select from 1 to 5.
Item Alignment
Click the drop-down to select, None, Left or Right.
Item Alignment Length
Enter the number of characters to fill with the Align Filler Character.
Align Length is the number of characters to fill if the counter value if less than the maximum
number. Its main purpose is to make the field length consistent no matter what the counter
value.
For example:
Counter Max Number (Counter Module) = 10000
Counter Current Value = 500
Align Filler Char = X
Counter shown in Image Name = XX500 (Left Alignment) or 500XX (Right Alignment)
Item Alignment Filler
Enter a filler character to use with Align Length.
Item Data Format
Click the drop-down to select, Decimal, Hexidecimal, Numeric, Bitmap
STRING ITEMS:
Item Alignment Length
Enter the number of characters to fill with the Align Filler Character.
Align Length is the number of characters to fill if the counter value if less than the maximum
number. Its main purpose is to make the field length consistent no matter what the counter
value.
For example:
Counter Max Number (Counter Module) = 10000
Counter Current Value = 500
Align Filler Char = X
Counter shown in Image Name = XX500 (Left Alignment) or 500XX (Right Alignment)
Item Alignment Filler
Enter a filler character to use with Align Length.
Link to Code
Select Disabled, Previous Code, or Next Code from the drop-down list.
•
Disabled: A code will not be linked to this text string
•
Previous Code: The text string will be linked to the previous generated code
•
Next Code: The text string will be linked to the next generated code
NOTE: Length, Width, Height, and Volume are only used if there is a
DM3610 in your system.
