MANUAL MOUNTING CALIBRATION
252 AV7000 LINEAR CAMERA
Image Gain
The image gain affects the camera’s ability to decode the barcodes by modifying the
image exposure. Increased gain increases the brightness and clarity of an image at a
given exposure.
1. From the menu tree, navigate to Diagnos
tic | Image Viewer. The Image Viewer
window opens.
2. Again run the text box through the system with the targets facing the camera.
3. In the Imag
e Viewer, hold the mouse pointer over any white area of the target.
LPI/DPI Calibration
Lines Per Inch (LPI) and Dots Per Inch (DPI) values read by the AV7000 must be within
5% of each other. The goal is for the AV7000 to capture square pixels. This is especially
important with certain barcodes and in cases where Optical Character Recognition
(OCR) is required.
1. From the menu tree, navigate to Diagnos
tic | Image Viewer. The Image Viewer
window opens.
2. Run the prepared test box through the system.
3. Click to zoom into the captured image of the Dynamic F
ocus Target so one circle
fills the screen.
4. While holding down the CTRL key, click and drag a box from the middle of the cen-
ter dot to the outer edges of the outer circle as shown below. This image is obvi-
ously elongated, and corrections must be made.
NOTE: If necessary, hold the Shift key an
d click to zoom back out. Alternately, rotate the
mouse wheel to zoom in or out.
