Datalogic AV7000 User Manual

ERROR CODES AND RESOLUTIONS
PRODUCT REFERENCE GUIDE 419
Error: FSM PWM Over Time Error
The focus servo exceeding
the maximum PWM time-
outs attempting to get to the
commanded position.
The shipping lock is still
engaged or partially engaged.
There is an internal hardware
failure.
Verify the shipping lock is fully dis-
engaged. Cycle the unit’s power. If
the error persists, replace the cam-
era and/or contact Datalogic Sup-
port.
Error: FSM Servo reception Error
The camera is unable to
receive messages from the
focus servo.
Internal communication fail-
ure.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: FSM Servo Transmis-
sion
Error
The camera is unable to send
messages to the focus
servo.
Internal communication fail-
ure.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: GPIO Handler stopped
responding
Error
The GPIO Handler application
has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Illumination exceeded
max temp
Error
The illumination exceeded
the maximum internal tem-
perature
Ambient temperature has
exceeded the maximum 50
degrees C operating tempera-
ture. There is a fan failure or
airflow blockage.
Verify the ambient temperature is
less than or equal to 50 C. Check
the fan operation and for any air-
flow obstructions, particularly at
the ends of the illumination.
Replace fans if necessary.
Error: Illumination Mon
stopped responding
Error
The Illumination Monitor
application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Image Line Handler
stopped responding
Error
The Image Line Handler
application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Image Sensor Mon
stopped responding
Error
The Sensor Monitor applica-
tion has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Interrupt Handler
stopped responding
Error
The Interrupt Handler appli-
cation has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: LED Bar Failed Error
The illumination controller
has indicated an issue with a
LED module.
An internal failure occurred in
the illumination.
Cycle the unit’s power. Verify all of
the LED modules in illumination
come on. If the error persists,
replace the illumination and/or
contact Datalogic Support.
Error: Network Logger
stopped responding
Error
The Network Logger Monitor
application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Network Rx stopped
responding
Error
The Network Receive Moni-
tor application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Network TX stopped
responding
Error
The Network Transmit Moni-
tor application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Parameter Manager
stopped responding
Error
The Parameter Manager
application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
Error: Position Sensor Too
Close to Camera
Error
The position sensor is
mounted too close to the
camera and incoming focus
data cannot be processed.
The camera is mounted too
close to the position sensor or
the distance to scan line
parameter is not set properly.
Check the distance to scan line
parameter. The camera will need to
be moved if the distance to scan
line parameter is set to the correct
value.
Error: Proc Tach Array stopped
responding
Error
The Process Tach Array
application has stopped.
The application has stopped
responding or crashed.
Cycle the unit’s power. If the error
persists, replace the camera and/or
contact Datalogic Support.
e-Genius Description Type Explanation Possible Cause Solution
