TECHNICAL FEATURES
436
AV7000 LINEAR CAMERA
Common
Communication
Interfaces
Main Baud Rate
RS232/RS422 up
to 115.2 Kbit/s
1200 to 115200
Auxiliary
RS232 up to
115.2 Kbit/s
1200 to 115200
Ethernet
2 x Ethernet TCP/IP
1 Ethernet Gigabit for decoding data to Host (may also
be used for setup)
1 Ethernet Gigabit for image file transfer to Host
Digital Inputs
3 x Inputs (2 + 1 x “Encoder”), optocoupled, NPN/PNP (5-30 Vdc)
1 Presence Sensor opto-isolated (polarity insensitive)
1 Optical Encoder opto-isolated (polarity insensitive)
1 General Purpose opto-isolated (polarity insensitive)
Digital Outputs
2 x Outputs SW programmable, optocoupled, event driven, NPN
2 General Purpose opto-isolated open collector or open emitter
Optional Setup
Interface
1 USB 2.0 port for Keyboard/Mouse Hub + 1 VGA
port for System Monitor
Internal
Communication
System
SyncNet Technology
Fieldbus
All common Fieldbus communications supported through various Fieldbus
modules installed in the CBX800 connection box.
OPTICAL FEATURES
Sensor Type
High Speed CMOS Line Scan - 8192 pixels
Optical Lens
90 mm, 110 mm and 140 mm *
View Angle
8° to 45° *
Max Scan Rate
30 kHz scans/sec
FOV from Top
up to 1400 mm *
DOF from Top
up to 1200 mm *
Resolution
110 to 260 pixels/inch (DPI) *
Focus
Dynamic
* Depends on model and/or application type
ELECTRICAL FEATURES
Supply Voltage
23-26VDC at illumination connector
