PRODUCT REFERENCE GUIDE
437
HUMAN MACHINE INTERFACE
Keypad
2 buttons
LED Indicators
Status, Tach,Trigger
HARDWARE FEATURES
Decoder CPU
Dual-core Intel® Celeron®, optional Intel® Core™ i5
Operating System
Linux
RAM
8 Gb
Parameter Storage
4 Gb Non-volatile internal FLASH
SOFTWARE FEATURES
Device Programming
Multilanguage, browser-based, on board HTML web server interface
Readable Barcodes
All Standard 1D and 2D Symbologies
ENVIRONMENTAL FEATURES
Temperature
Operating: 0° to 50° C [32° to 122° F]
Storage: -20° to 70° C [-4° to 158° F]
Relative Humidity
95% non condensing
Vibration Resistance
SINE vibration as per EN60068-2-6
5-9Hz : 1.5mm / 9-150Hz :0.5g
2h on the primary axis (perpendicular to the face of the camera)
Shock Resistance
As per EN60068-2-27, 15g / 11ms / 3 times up and 3 times down on the
primary axis.
Protection Class
IP65
Fan Life
L10 @ 50°C : 50000h
PHYSICAL FEATURES
Mechanical Dimensions:
AV7000 with external fans and Short
Illumination
845x416x237 mm [33.3x16.4x9.3 in]
AV7000 with external fans and
Medium Illumination
1150x416x237 mm [45.3x16.4x9.3 in]
AV7000 with external fans and long
Illumination
1480x416x237 mm [58.3x16.4x9.3 in]
Weight
AV7000
11 kg [24 lbs]
Illumination Short, Medium, Long
12 kg [26 lbs], 15 kg [33 lbs], 19 kg [41 lbs]
Enclosure
Aluminum Alloy
Connections
FAN, I/O, FOCUS SER, POWER, HOST NET, IMAGE NET, FOCUS NET, SYNC
OUT, SYNC IN
OTHER
Service Options
Installation services and on-site training
Warranty
2-year limited, parts and labor
ELECTRICAL FEATURES
Supply Voltage
23-26VDC at illumination connector
