Service Tests and Utilities
3-24 Designjet Z Series — Service Manual
 Starting DelSol1.
 Getting PCA Revision.
 Checking Memory Size.
 Getting Memory Size.
17 The Front Panel then displays Formatter Memory Size and prompts you to
press any key to continue.
18 Press any key to continue.
19 The Formatter hard disk test starts and the Front Panel displays the following
messages:
 Starting DelSol1.
 Getting PCA Revision.
 Checking Memory Size.
 Getting HDA info.
20 The Front Panel then displays Formatter Hard Disk information test results and
prompts you to press any key to continue.
21 Press any key to continue.
22 The Formatter hard disk file information test starts and the Front Panel
displays the following messages:
 Starting DelSol1.
 Getting PCA Revision.
 Checking Memory Size.
 Getting HDA Info.
 Getting File System Info.
23 The Front Panel then displays Formatter Hard Disk File information test results
and prompts you to press any key to continue.
